MC CHANNELS

STANDARD*
DIM SIZE RANGE
A 1.00"-9.00"
B 1.00"-9.00"
C 0.188" & LARGER
D 0.188 & LARGER
WELDED**
DIM SIZE RANGE
A 7.00"-18.00"
B 2.00-6.00"
C 0.188" & LARGER
D 0.188 & LARGER
  • Random lengths or cut lengths.
  • No tooling charge on standard stainless structural.

    * If the configuration of A + B
      dimensions exceeds a 6.5"
      circle size, a minimum order
      quantity of 15,000 lbs.may
      be required depending
      on the size.

    ** Only one weld joins two
        extruded angles to create
        a weld channel.


C CHANNELS

STANDARD*
DIM SIZE RANGE
A 1.00"-9.00"
B 1.00"-9.00"
C 0.188" & LARGER
D 0.188 & LARGER
WELDED
DIM SIZE RANGE
A 7.00"-18.00"
B 2.00-6.00"
C 0.188" & LARGER
D 0.188 & LARGER
  • Random lengths or cut lengths.
  • No tooling charge on standard stainless structural.

    * If the configuration of A + B
      dimensions exceeds a 6.5"
      circle size, a minimum order
      quantity of 15,000 lbs.may
      be required depending
      on the size.
