Pipe
Sizes
Available in 304, 316 and Other Grades
| SIZE |
SCHEDULES |
OD |
AW |
LENGTH |
Estimated
WT/FT. |
| 2" |
40 |
2.375" |
.154" |
23'
- 27' |
3.65 |
| 2" |
80 |
2.375" |
.218" |
20'
- 24' |
5.02 |
| 2" |
160 |
2.375" |
.343" |
12'
- 16' |
7.44 |
| 2" |
XXHvy |
2.375" |
.436" |
24'
- 28" |
9.03 |
| 2
1/2" |
40 |
2.875" |
.203" |
24'
- 28' |
5.79 |
| 2
1/2" |
80 |
2.875" |
.276" |
20'
- 24' |
7.66 |
| 2
1/2" |
160 |
2.875" |
.375" |
20'
- 24' |
10.01 |
| 2
1/2" |
XXHvy |
2.875" |
.552" |
20'
- 24' |
13.69 |
| 3" |
40 |
3.500" |
.216" |
25'
- 29' |
7.58 |
| 3" |
80 |
3.500" |
.300" |
18'
- 22' |
10.25 |
| 3" |
160 |
3.500" |
.438" |
17'
- 22' |
14.32 |
| 3" |
XXHvy |
3.500" |
.600" |
12'
- 16" |
18.58 |
| 3
1/2" |
40 |
4.000" |
.226" |
24'
- 28' |
9.11 |
| 3
1/2" |
80 |
4.000" |
.318" |
21'
- 25' |
12.50 |
| 3
1/2" |
XXHvy |
4.000" |
.636" |
12'
- 16' |
22.84 |
| 4" |
40 |
4.500" |
.237" |
23'
- 27' |
10.79 |
| 4" |
60 |
4.500" |
.281" |
18'
- 22' |
12.66 |
| 4" |
80 |
4.500" |
.337" |
23'
- 27' |
14.98 |
| 4" |
120 |
4.500" |
.438" |
17'
- 21" |
19.00 |
| 4" |
160 |
4.500" |
.531" |
14'
- 18' |
22.51 |
| 4" |
XXHvy |
4.500" |
.674" |
11'
- 15' |
27.54 |
| 5" |
40 |
5.563" |
.258" |
18'
- 22' |
14.62 |
| 5" |
80 |
5.563" |
.375" |
12'
- 16' |
20.78 |
| 5" |
120 |
5.563" |
.500" |
8'
- 12' |
27.04 |
| 5" |
160 |
5.563" |
.625" |
6'
- 10" |
32.96 |
| 5" |
XXHvy |
5.563" |
.750" |
5'
- 9' |
38.55 |
| 5
to 8" |
NOTE:
Longer lengths for 5" Schedule 120 thru 8" schedule
80 require a minimum order quantity of 5,000 pounds.
|
|
